Product Description
Ariens/Gravely Tractor Seat F20 Series F20M5145 Low Pro Air Suspension, Gray Vinyl
| Suspension stroke 2" / 50.8mm | |
| • Slide track travel 6" / 150mm | |
| • Weight adjustment 110 - 330 lbs. / 150kg | |
| • Mechanical lumbar support | |
| • Ergonomic design | |
| • Multi-angle adjustable backrest, adjustable headrest & fold-up armrests | |
| • Seat cushion & backrest are removeable. OPS & seat belt included | |
| • Flat pad style operators presence switch is installed in between seat cushion and pan | |
| • Heavy duty construction, some assembly required | |
| • All dimensions & specifications must be checked before ordering. This is a universal seat meant for a flat mounting surface. Some applications may require drilling & bracket fabrication to mount seat | |
| Amperage | 9 Max |
| Includes | F20 Series gray vinyl seat / low profile air suspension / slide tracks / armrests / headrest / OPS / seat belt |
SEE LIST BELOW FOR COMPATIBLE MACHINES
- Prices subject to change without notice.
- Most seats are shipped LTL.
